INTRODUCTION
This document covers the installation and commissioning of a JUNO-NET fire alarm system. This document is intended
for use by a competent, qualified, fire alarm installation engineer.
The JUNO-NET fire alarm system is highly modular and each system should be tailored to the building requirements. The
complete system should be designed to meet all applicable regulations. The installation must then be performed in
accordance with the system design. This manual not only clarifies the components and connections during installation
but will also assist in commissioning and maintenance.
This manual covers the installation and commissioning of a complete system. There is a separate Operation and
Maintenance Manual.
All PCBs contain Electrostatic Sensitive Devices.
Take suitable ESD (Electrostatic Discharge) precautions when removing or installing printed circuit boards (PCBs).
EN-54 INFORMATION
In accordance with EN54 pt.2 1997 / AC: 1999, clause 13.7, the maximum number of sensors and/or manual call points in
this panel, will not exceed 512 units.
This fire Detection Control Panel complies with the requirements of EN54 pt. 2 and 4 1997 / AC: 1999. In addition to the
requirements of the above mentioned standard, the unit conforms to the following optional functions:
OPTION EN54 pt.2 Clause
Fault Signals from points 8.3
Delays for activation of outputs 7.11
Disablement of each addressable point 9.5
Test Condition 10
Outputs to fire alarm devices 7.8
In addition to the functions required by the standard EN54 pt. 2 1997 / AC: 1999, the panel supports ancillary functions
that are not required by the above mentioned standard, namely:
Ancillary Functions
Panel network connection ports.
Panel to PC graphics software output port.
Panel to PC programming software (upload/download) port.
Remote class change input extension board connector.
Internal and External Printer.
Auxiliary relays outputs.
Indication
Controls
Outputs
ELECTRO-STATIC SENSITIVE DEVICES (ESD)
TAKE SUITABLE ESD PRECAUTIONS WHEN REMOVING OR
INSTALLING PRINTED CIRCUIT BOARDS.
OVERVIEW
7
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
