7
7-1
7-2
7-3
Monitor Device Counts & Test
Device Count, Type & Value
Use this function to check that all Sub-panels are present and that all devices are present.
Use +/- to select the Analogue Loop number and 0-9 and to select the device address on that loop.
This function is also useful to confirm the address of the various different types of devices connected to the Analogue
Loops.
Note that in Installation Mode all information is live i.e. the count of devices will change as the panel learns and device
types will be updated if they change. In Active Mode only the device value is live.
Test Sounders
Use this function to test the audibility of the sounders in a more comfortable manner than pressing SOUND ALARMS.
Main Panel
The Main Panel Conventional Sounders will sound for 1 second then be silenced for 9 seconds.
Standard Sub-panels
Conventional Sounders and Loop Sounders are operated for 1 second then silenced for 9 seconds.
Integrated Sub-panels
Conventional Sounders and Loop Sounders are operated for 1 second then silenced for 9 seconds.
Conventional Sounder operation for a Repeater Integrated Sub-panel will be synchronized to the Loop Sounder
operation.
Sounders on Test Activation
This function allows you to choose an audible confirmation that a device has detected a fire. The audible confirmation
consists of a 1 second period of sounder operation. The settings selected by this function are used by ‘7-4 Test Zones’ and
‘6-4-1 Activate ASET Mode (SAM)’.
ALL SOUNDERS ON DETECTOR TEST activates the Main Panel Conventional Sounders and all Conventional Sounders
and Loop Sounders on the Sub-panel under test.
SUB_PANEL SOUNDERS ON DETECTOR TEST only operates the Conventional Sounders and Loop Sounders on the Sub-
panel under test. I.e. The Sub-panel that the detector under test is physically connected to.
NOTE: using this function AFTER ‘7-4 Test Zones’ and ‘6-4-1 Activate ASET Mode (SAM)’ will NOT
change the settings for the zones already in test mode and the loops already in ASET mode.
91
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
