NVRAM
PCB
Repeater
SIM CARD
Sub-panel
The System
Zone
Non-volatile Random Access Memory. Any information stored in this memory will not be cleared when power is
removed from the system. The system has an internal battery for the NVRAM.
Printed Circuit Board.
A Repeater is a remote terminal to the Main Panel. Everything that is displayed on the Main Panel is also displayed on
the Repeater. Any LEDs illuminated on the Main Panel are illuminated on the Repeater. Key presses and programming
input at the Repeater are sent directly to the Main Panel, as if the input were actually occurring at the Main Panel.
Single In-line Memory Card. Fitted to the SIM CARD is the Flash memory that contains the Main Panel software and
the system settings (Customer Flash Memory ).
These provide the Analogue Loops. Each Sub-panel supports one or three Analogue Loops. There are two types of
Sub-panels: Integrated and Standard. An integrated sub-panel consists of a loop card installed onto either the Main
panel or Repeater Motherboard. A standard Sub-panel consists of a loop card installed on a Sub-panel board which
is a basic fire control panel with its own CPU, local memory and fire signaling outputs. The Sub-panel reports all
events to the main panel but can operate individually in the event of communication loss. Up to 3 standard Sub-
panels can be housed within a Main Panel box. Additional Standard Sub-panels can be housed externally , and
typically, will be distributed around the building.
Sub-panels are connected to the Main Panel via the Data Loop.
The Main Panel, Sub-panels, Repeaters, and all devices.
A situational group of devices. A Zone can consist of a collection of any of the devices connected to the system.
