Grandstream Networks GWN76 Series User Manual

P a g e | 32
GWN76XX User Manual
Version 1.0.19.25
Frequency Bands
2.4GHz Radio: 2412 – 2484 MHz
5 GHz Radio: 5180-5825 MHz
Channel Bandwidth
2.4G: 20 and 40MHz
5G: 20, 40 and 80 MHz
Wi-Fi and System
Security
WEP, WPA3, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot
and critical data/control lockdown via digital signatures, unique security certificate
and random default password per device
MIMO
2×2:2 2.4GHz (MIMO)
2×2:2 5GHz (MU-MIMO))
Coverage Range
Up to 250 meters
*coverage range can vary based on environment
Maximum TX Power
2.4G: 24 dBm
5G: 22dBm
Receiver Sensitivity
2.4G
802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -
75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm
@MCS7
5G
802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -
67dBm@MCS8; 802.11ac: HT40:- 63dBm @MCS9; 802.11ac 80MHz: -59dBm
@MCS9
SSIDs
16 SSID per access point.
*GWN7605LR when deployed as Master can only be added to 8 SSIDs.
Concurrent Clients
100+
Network Interfaces
2× autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports
1× Reset Pinhole
Mounting
Outdoor metal bar mount or wall mount, kits included
LEDs
1 tri-color LED for device tracking and status indication
Network Protocols
IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS
802.11e/WMM, VLAN, TOS
Network
Management
Embedded controller can manage up to 50 local GWN APs
GWN.Cloud offers a free cloud management platform for almost unlimited GWN
Aps
GWN.Manager offers premise-based software controller for up to 3,000 GWN APs
Power and Green
Energy Efficiency
POE 802.3af/ 802.3at;
Maximum Power Consumption: 10.16W
