GWN76XX User Manual
Version 1.0.19.25
Environmental
Operation: -30°C to 60°C
Storage: -30°C to 70°C
Humidity: 10% to 90% Non-condensing
Physical
Physical Unit Dimension: 358.3mm(L)*115mm(W)*45.3mm(H); Unit Weight: 500g
Entire Package Dimension: 258 × 247× 86mm; Entire Package Weight:655.3g
Package Content
GWN7605LR 802.11ac Wave-2 Wireless AP, Mounting Kits, Quick Start Guide
Water Proof
IP66-level weatherproof capability when installed vertically
Compliance
FCC, CE, RCM, IC
Table 4: GWN7600 Technical Specifications
Wi-Fi Standards
IEEE 802.11 a/b/g/n/ac (Wave-2)
Antennas
2x 2.4 GHz, gain 3 dBi, internal antenna, 2x 5 GHz, gain 3 dBi, internal antenna
Wi-Fi Data Rates
IEEE 802.11ac: 6.5 Mbps to 877 Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5 Mbps to 300 Mbps; 400 Mbps with 256-QAM on 2.4GHz
IEEE 802.11b: 1, 2, 5.5, 11 Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental
conditions, distance between devices, radio interference in the operating
environment and mix of devices in the network.
Frequency Bands
2.4GHz radio : 2.400 - 2.4835 GHz
5GHz radio: 5.150 - 5.250 GHz, 5.725 - 5.850 GHz
Channel Bandwidth
2.4G: 20 and 40 MHz
5G: 20,40 and 80 MHz
Wi-Fi and System
Security
WEP, WPA3, WPA/WPA2‐PSK, WPA/WPA2‐Enterprise (TKIP/AES), anti-hacking
secure boot and critical data/control lockdown via digital signatures, unique
security certificate and random default password per device.
MIMO
2x2:2 2.4GHz,
2x2:2 5GHz
Coverage Range
Up to 541ft. (165 meters) for GWN7600.
*Coverage range can vary based on environment
Maximum TX Power
5G: 22dBm
2.4G: 22dBm
*Maximum power varies by country, frequency band and MCS rate.
