GWN76XX User Manual
Version 1.0.19.25
Advanced
SSID Hidden
Select to hide SSID. SSID will not be visible when scanning for Wi-Fi, to
connect a device to hidden SSID, users need to specify SSID name and
authentication password manually.
DTIM Period
Configures the frequency of DTIM (Delivery Traffic Indication Message)
transmission per each beacon broadcast. Clients will check the AP for
buffered data at every configured DTIM Period. You may set a high value
for power saving consideration.
 Default value is 1, meaning that AP will have DTIM broadcast
every beacon.
 If set to 10, AP will have DTIM broadcast every 10 beacons.
Valid range: 1 – 10.
Client Inactivity Timeout(s)
AP will remove the client's entry if the client generates no traffic at all for
the specified time period. The client inactivity timeout is set to 300 seconds
by default. Range from 60-3600 seconds.
Client Bridge Support
Configures the client bridge support to allow the access point to be
configured as a client for ridging wired only clients wirelessly to the
network. When an access point is configured in this way, it will share the
Wi-Fi connection to the LAN ports transparently.
Once an SSID has Client Bridge Support enabled, the AP adopted in this
SSID can be turned in to Bridge Client mode by click the Bridge button.
Note: This feature isn't supported on GWN7602.
Client Time Policy
Select a time policy to be applied to all clients connected to this SSID.
Multicast/Broadcast
Suppression
When set to “Disable”: all of the broadcast and multicast packages will be
forwarded to the wireless interface.
When set as “Enabled”: all of the broadcast and multicast packages will
be discarded except DHCP/ARP/IGMP/ND;
When set to “Enable with Proxy ARP enabled”: AP will enable the
optimization with Proxy ARP enabled in the meantime.
Convert IP multicast to
unicast
When set to “Disabled”: none of the multicast package will be converted;
Passive mode: AP will never initiatively broadcast IGMP queries, and the
IGMP snooping item will be aged out 300 seconds after it is registered,
which may result in the failure of forwarding multicast data.
Active mode: AP will initiatively broadcast IGMP queries to keep updating
of the IGMP snooping items.
Enable Schedule
Enable this option to assign a schedule for the bandwidth rule.
