WR1000-UM-251–01–9380 6 – 9
6. INSPECTION AND CHECK PROCEDURES
Setting Procedure
(1) Press the main control panel’s
MODE
key to select RECORDER as the measurement mode.
(2) Press the
RECORD
key on the Conditions panel to respectively display the Record Settings and Format
Settings windows. At each window, use the arrow keys to move the cursor to the desired parameter, then
use the
ENTER
key and arrow keys to enter the following settings.
Fig. 6-2-9. Record Settings window
Display Mode Y-T
Function Direct
Chart Speed 5mm/s
Fig. 6-2-10. Format Settings window
Record Format 200mm × 1
Grid None
Width 1 dot
