OPERATION
127
Step
Assigns the step number.
Time
Sets the step duration time. This
step time is exclusive of any
transition time needed to match
start phases. See the diagram on
page 129 for details.
Jump To
The Jump To setting determines
which step to jump to at the end of
the step. If Jump To is turned off,
the unit will follow the Term (Step
termination) setting for the step.
Jump Cnt.
Determines the number of times to
loop the jump step.
Branch1/
Branch2
The Branch settings allow you to
make a selectable branch within the
sequence when the sequence is
running or on hold. The branch1 or
branch2 actions are enabled by
pressing the F1 or F2 function keys,
or by using
the :TRIG:SEQ:SEL:EXEC remote
control command. After the branch
step(s) have completed the unit will
return back to the step from which
the branch was executed and
continue to run the step from where
it left off.
