117
LPU Description
Conne
ctor
Number
of
interfaces
Interface
transmission rate
Available
transceiver
modules
LSQ1TGS8
SC0
8-port 10-Gigabit optical
SFP+ interface card
LC 8 10 Gbps
10-Gigabit
SFP+
module
10-Gigabit
SFP+ cable
LSQ1TGS1
6SC0
16-port 10-Gigabit optical
SFP+ interface card
LC 16 10 Gbps
10-Gigabit
SFP+
module
10-Gigabit
SFP+ cable
LSQ1TGX2
SC0
2-port 10-Gigabit optical
Ethernet interface card (XFP,
LC)
LC 2 10 Gbps
10-Gigabit XFP
module
RJ-45 24
10/100/1000
Mbps,
half/full-duplex
LSQ1GV24
PSC0
20-port Gigabit electrical
interface (RJ-45) + 4-port
Gigabit Combo interface
card-PoE
LC 4 1000/100 Mbps
Gigabit SFP
module
100-Mbps
SFP module
24 1000/100 Mbps
Gigabit SFP
module
100-Mbps
SFP module
LSQ1P24X
GSC0
24-port Gigabit optical
interface (SFP, LC) +2-port
10-Gigabit optical interface
(XFP, LC) card
LC
2 10 Gbps
10-Gigabit XFP
module
RJ-45 24
10/100/1000
Mbps,
half/full-duplex
LSQ1T24X
GSC0
24-port Gigabit electrical
interface (RJ-45) +2-port
10-Gigabit optical interface
(XFP, LC) card
LC 2 10 Gbps
10-Gigabit XFP
module
RJ-45 40
10/100/1000
Mbps,
half/full-duplex
LSQ1GV40
PSC0
40-port Gigabit electrical
interface (RJ-45) +8-port
Gigabit optical interface
(SFP, LC) card
LC 8 1000/100 Mbps
Gigabit SFP
module
100-Mbps
SFP module
SC 4 1000 Mbps
EPON interface
module
LSQ1PT4PS
C0
4-port Gigabit passive
optical interface (EPON OLT
SFP, SC) +8-port Gigabit
optical interface (SFP, LC)
card
LC 8 1000/100 Mbps
Gigabit SFP
module
100-Mbps
SFP module
