H3C S7500E Series Installation Manual

118
LPU Description
Conne
ctor
Number
of
interfaces
Interface
transmission rate
Available
transceiver
modules
SC 8 1000 Mbps EPON module
LSQ1PT8PS
C0
8-port Gigabit passive
optical interface (EPON OLT
SFP, SC) +8-port Gigabit
optical interface (SFP, LC)
card
LC 8 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
SC 16 1000 Mbps EPON module
LSQ1PT16
PSC0
16-port Gigabit passive
optical interface (EPON OLT
SFP, SC) +8-port Gigabit
optical interface (SFP, LC)
card
LC 8 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
SC 4 1000 Mbps EPON module
LSQ4PT4PS
C0
4-port Gigabit passive
optical interface (EPON OLT
SFP, SC) +8-port Gigabit
optical interface (SFP, LC)
card
LC 8 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
SC 8 1000 Mbps EPON module
LSQ4PT8PS
C0
8-port Gigabit passive
optical interface (EPON OLT
SFP, SC) +8-port Gigabit
optical interface (SFP, LC)
card
LC 8 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
SC 16 1000 Mbps EPON module
LSQ4PT16
PSC0
16-port Gigabit passive
optical interface (EPON OLT
SFP, SC) +8-port Gigabit
optical interface (SFP, LC)
card
LC 8 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
LC 24 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
LSQ1GP24
TSD0
16-port Gigabit optical
Ethernet interface (SFP, LC)
+ 8-port Gigabit combo
interface card
RJ-45 8
10/100/1000
Mbps,
half/full-duplex
—
24 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
LC
2 10 Gbps
10-Gigabit XFP
module
LSQ1GP24
TXSD0
16-port Gigabit optical
Ethernet interface (SFP, LC)
+ 8-port Gigabit combo
interface + 2-port
10-Gigabit optical interface
(XFP, LC) card
RJ-45 8
10/100/1000
Mbps,
half/full-duplex
—
