H3C S7500E Series Installation Manual

119
LPU Description
Conne
ctor
Number
of
interfaces
Interface
transmission rate
Available
transceiver
modules
LSQ1GP48
SD0
48-port Gigabit optical
Ethernet interface card (SFP,
LC)
LC 48 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
LSQ1GV48
SD0
48-port Gigabit electrical
Ethernet interface card
(RJ-45)-PoE Plus
RJ-45 48
10/100/1000
Mbps,
half/full-duplex
—
LSQ1TGX2
SD0
2-port 10-Gigabit optical
Ethernet interface card (XFP,
LC)
LC 2 10 Gbps
10-Gigabit XFP
module
LSQ1TGX4
SD0
4-port 10-Gigabit optical
Ethernet interface card (XFP,
LC)
LC 4 10 Gbps
10-Gigabit XFP
module
LSQ1TGX8
SD0
8-port 10-Gigabit optical
Ethernet interface card (XFP,
LC)
LC 8 10 Gbps
10-Gigabit XFP
module
LSQ1GP12
EA0
12-port Gigabit optical
Ethernet interface card (SFP,
LC)
LC 12 1000 Mbps
Gigabit SFP
module
LSQ1TGX1
EA0
1-port 10-Gigabit optical
Ethernet interface card (XFP,
LC)
LC 1 10 Gbps
10-Gigabit XFP
module
LC 24 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
LSQ1GP24
TEB0
16-port Gigabit optical
Ethernet interface (SFP, LC)
+ 8-port Gigabit combo
interface card
RJ-45 8
10/100/1000
Mbps,
half/full-duplex
—
LSQ1GP48
EB0
48-port enhanced Gigabit
optical Ethernet interface
card (SFP, LC)
LC 48 1000/100 Mbps
• Gigabit SFP
module
• 100-Mbps
SFP module
LSQ1TGX2
EB0
2-port 10-Gigabit optical
Ethernet interface card (XFP,
LC)
LC 2 10 Gbps
10-Gigabit XFP
module
LSQ1TGX4
EB0
4-port 10-Gigabit optical
Ethernet interface card (XFP,
LC)
LC 4 10 Gbps
10-Gigabit XFP
module
NOTE:
• For the transceiver modules that each LPU supports, see “Transceiver modules.”
• A co
mbo port is a logical port that comprises an SFP interface and an RJ-45 Ethernet interface. Only
one of them can be activated at a time.
