H3C S7500E Series Installation Manual

40
Table 10 Cards supporting PoE
Card model
Number of
POE-capable
ports
PoE DIMM PoE type
LSQ1GV48SD0 48 No PoE DIMM needed Type1, Type2
LSQ1CGV24PSC0 24
LSQ1GV24PSC0 24
LSQ1GV24PSA0 24
24-port PoE DIMM (LSQM1POEDIMMS0)
LSQ1FV48SA0 48
LSQ1GV48SA0 48
LSQ1GV48SC0 48
LSQ1GV40PSC0 40
PoE master/subordinate DIMM
(LSBM1POEDIMMH)
Type 1
NOTE:
The following PoE types are available:
• Type 1—Power delivered by a single port: 0 to 15.4 W; volta
g
e ran
g
e: 44 V to 57 V; maximum current:
350 mA. This PoE type provides power to classes 0 to 3 PDs.
• Type 2: Power delivered by a single port: 0 to 30 W, voltage range: 50 V to 57 V, maximum current:
600 mA. This PoE type provides power to classes 0 to 4 PDs.
Power modules supporting PoE
• The power modules PSR650-A/PSR650-D/PSR320-A/PSR320-D for the S7502E and S7503E-S do
not support PoE. To enable PoE on these switches, use an external PoE power supply (for example,
RPS800-A). For how to connect an external PoE power supply, see “Connecting an external PoE
po
w
er supply.”
• To implement PoE on the S7503E, S7506E, S7506E-V, or S7510E, you can select power modules
supporting PoE. For description of the power modules supporting PoE, see Table 11.
Table 11 Power modules supporting PoE
Power module
model
PoE maximum power output
Separate
PoE power
cable
Power cable connection
PSR1400-D 6720 W No
Connecting the PSR1400-D power
cab
le
1150 W (110 V)
PSR2800-ACV
1400 W (220 V)
Yes
Connecting the PSR2800-ACV power
cab
le
