Always use the appropriate fuse listed in this table
Code Description Code Amp. (A) Description
F1 3.0 not used F29 15.A front side cabin lights
F2 10 A side lights/backlighting F30 15 A starter contactor
F3 3 A 12 V BAT - ceiling F31 10 A starter solenoid
F4 15 A flasher unit - control F32 15 A dipped beam
F5 15 A not used F33 15 A main beam headlights
F6 15 A not used F34 10 A work area lighting (optional)
F7 30 A 12V BAT - air conditionning F35 25 A windscreen washer pump - windscreen wipers
F8 5 A 12V BAT - car radio F36 7.5 A acoustic alarm
F9 7.5 A rear view mirrors F37 10 A 12 V after ignition - 4-wheel steering
F10 5 A air conditioning compressor F38 10 A 12 V after ignition - optional
F11 7.5 A front hydraulic motor capacity F39 10 A 12 V after ignition - optional
F12 15 A rear hydraulic motor capacity F40 10 A 12 V after ignition - adjustable track width VTK only
F13 15 A 12V BATT -Trimble CFX750- optional F41 10 A 12 V after ignition - Off-Road unit
F14 15 A 12V BATT - AutoHeight control- optional F42 10 A road- parking - 4-wheel drive standard mode
F15 15 A 12V BATT - adjustable track width VTK only- optional F43 5.0 A brake lights
F16 15 A 12V BATT - adjustable track width controller VTK only F44 7.5 A 12 V after contact with SD module- input 1
F17 15 A 12V BATT - optional F45 7.5 A permanent 12 V battery - HC9500 console
F18 20 A flasher unit F46 7.5 A 12 V after contact with SD module- input 2
F19 15 A boom ligts 1 and 2 (HC9500 only) F47 5 A not used
F20 15 A boom ligts 3 and 4 (HC9500 only) F48 5 A Footbridge control
F21 15 A hazard lights F49 5 A brake pressure - hydraulic level - alarms
F22 15 A cigarette lighter - 12V sockets F50 5 A hydraulic oil level alarm
F23 15 A seat compressor unit F51 7.5 A 12 V after ignition - engine error reversing buzzer
F24 15 A not used F52 5 A 12 V after ignition - ’CANCOCKPIT’ console-HC9500
F25 15.0 A right front cabin lights F53
5 A 12 V after ignition - right and left direction indicator
F26 15 A left rear cabin lights F54 5 A 12 V after ignition - cabin switches
F27 15 A not used F55 3 A 12 V after ignition - air conditioning and car radio
F28 15 A front cabin lights F56 3 A 12 V after ignition - J1939 diagnostic socket
Relays Description Relays Description
K01 not used (F5) K16 not used
K02 not used (F6) K17 backlighting - side lights
K03 air conditioning power K18 engine starter control
K04 air conditioning compressor K19 forward handle neutral position
K05 front hydraulic motor capacity K20 after ignition control circuit
K06 rear hydraulic motor capacity K21 after ignition control circuit
K07 boom ligts 3 and 4 (HC9500 only) K22 BRAKE lights
K08 boom ligts 1 and 2 (HC9500 only) K23 ROAD mode
K09 hazard lights K24 parking brake
K10 not used K25 work area lighting (optional)
K11 right rear cabin lights K26 not used
K12 left rear cabin lights K27 not used
K13 not used K28 Diff-Lock control (optional)
K14 front cabin lights
K15 front cabin side lights
