Vehicle equipment
Please note that this manual contains all
the standard equipment, country-specific
equipment and special equipment for this
model series. Thus, some equipment or
features described in this manual may not
be installed onto your vehicle or are only
available in some markets. For the further
configuration information, please refer to
relevant sales information or consult with
your distributor selling the vehicle to you.
Fuse
If any electrical components do not work,
the fuse may have been blown out. In this
case, it is recommended that inspections
should be carried out based on the follow-
ing operations and the fuses should be re-
placed if necessary:
1. Turn off all electrical components.
2. Turn the ignition switch to the LOCK
position, apply the parking brake and
disconnect the negative terminal of the
battery.
3. The fuses are located in the following
positions:
> Located in the fuse box of the engine
compartment
CEEDBD0AFEC8
Press and hold the two pawls at the
fuse box cover, and then pull up the
fuse box cover at the same time to
open the fuse box.
> Located in the instrument panel near the
steering wheel
37BB8DB6C6EE
Remove the box cover and you can
see it.
Caution
〉
Bringing water or other liquids into the
fuse box is forbidden, as this may dam-
age the electrical components.
〉
When installing the fuse box cover,
make sure it is properly located on the
fuse box. Otherwise, penetration of
moisture or dirt will affect the use of
Parts replacement
233
6
Maintenance
