HAVAL H6 2021 - Braking Parameters; Seat Parameters

Item Data
Alignment pa-
rameters
Rear
wheel
Rear wheel
camber
-0°64′±30′ (Left and right difference ≤30′)
Rear wheel
toe-in
0°4′±10′ (Left and right difference ≤10′)
Front
wheels
Kingpin
backwards
inclination
6.92°± 45′ (left and right difference ≤ 45′)
Kingpin in-
wards incli-
nation
12.44 °
Front-wheel
camber
-0°27′±45′ (Left and right difference ≤45′)
Front wheel
toe-in
0°8′±5′ (Left and right difference ≤5′)
Braking parameters
Item Data
Brake pedal Free travel [mm] 5~8
Front brake pad (friction ma-
terial)
Minimum thickness [mm] 2
Rear brake pad (friction ma-
terial)
Minimum thickness [mm] 2
Front brake disk Minimum thickness [mm] 26
Rear brake disk Minimum thickness [mm] 8
Seat parameters
Item Data
Seat slide rail design position Move 40 mm forward from the last position
Design angle of
seat backrest
Front seats 22°
Rear seats 25°
Common angle of
seat backrest
Front seats 22°~25°
Rear seats 25°
252
7
Technical data
