wiper blades.
〉
When using a wiper, leave streaks or
scratch.
Caution
When lifting and putting back the wiper,
you shall not pull the wiper blade directly
to avoid deformation or even damage.
1. Turn the ignition switch to the LOCK
position. Pull up the wiper control com-
bination switch to itself and hold it for
about 3s. Then, the wiper will automati-
cally reach the maintenance position,
as shown in the figure.
F496C9DD86A4
2. Lift the wiper arm from the windshield.
Caution
〉
To lift the wiper, be sure to bring the wip-
er to the service position. Otherwise, the
wiper will be damaged.
〉
Do not open the engine compartment
cover while the wiper is lifted. Doing so
can cause damage to the engine com-
partment cover and the wiper.
3. Rotate the wiper blade as indicated by
the arrow in the figure to maximize the
angle between it and the plastic con-
nector.
15E146B9A476
4. Remove the wiper blade from the wiper
arm.
3870D48F103F
Ⓐ Wiper blade
Ⓑ Flexible cleat
Press down on the flexible cleat and
pull the wiper blade in the direction in-
dicated at the same time until it sepa-
rates from the wiper arm.
Caution
When the wiper blade is not installed, nev-
er place the wiper arm directly on the
windshield as it is capable of scratching
235
6
Maintenance
