GigE Area Scan Camera User Manual

Trigger_in1 Trigger_in2 Trigger_in3

Trigger_in2

Trigger_in3

After Debounce

Debouncer Time Debouncer Time

Debouncer Time

Before Debounce

Figure 8-25 Sequence Diagram of Trigger Debouncer

Note

The sequence diagrams above use rising edge as trigger activation.
