HIKVISION DS-7732NI-I4/24P - Chapter 12 VCA Event Alarm; 12.1 Face Detection

Network Video Recorder User Manual
134
Chapter 12 VCA Event Alarm
The device supports receiving VCA detections sent by connected IP cameras. Enable and configure
VCA detection on the IP camera settings interface first.

VCA detections must be supported by the connected IP camera.

Refer to the network camera’s user manual for detailed VCA detection instructions.
12.1 Face Detection
Purpose
The Face Detection function detects the face appearing in the surveillance scene. Linkage actions
can be triggered when a human face is detected.
Step 1 Go to System > Event > Smart Event.
Step 2 Click Face Detection.
Figure 12-1 Face Detection
Step 3 Select a Camera to configure.
