Network Video Recorder User Manual
155
14.1.2 Configure POS Text Overlay
Step 1 Go to System > POS.
Step 2 Click Channel Linkage and Display tab.
Step 3 Select the linked channel to overlay the POS characters.
Step 4 Set the characters overlay for the enabled POS.
Character encoding format: currently the Latin-1 format is available
Overlay mode of the characters to display in scrolling or page mod
Font size and font color
Display time (sec) of the characters. The value ranges 5 -3600 sec.
Timeout of POS event. The value ranges 5 -3600 sec. When the device has not received the POS
message within the defined time, the transaction ends.
Step 5 In the Privacy Settings, set the POS privacy information to not display on the image, e.g., the card
number, user name, etc.
Step 6 Result: The defined privacy information will be displayed using ***on the image instead.
Step 7 (optional) Check the checkbox to enable the Overlay POS in Live View. When this feature is
enabled, the POS information is overlaid on the Live View image.
Figure 14-7 Overlay Character Settings
Drag the frame to adjust the textbox size and position on POS settings interface preview screen.
