HIKVISION DS-7732NI-I4/24P User Manual

Network Video Recorder User Manual
97
Table 8-1 Create Array Window
Step 3 Input the array name.
Step 4 Select RAID Level as RAID 0, RAID 1, RAID 5, RAID 6, or RAID 10 as required.
Step 5 Select the physical disks to constitute the array.
Table 8-2 Required Number of HDDs
RAID Level
Required Number of HDDs
RAID 0
At least 2 HDDs.
RAID 1
At least 2 HDDs.
RAID 5
At least 3 HDDs.
RAID 6
At least 4 HDDs.
RAID 10
The number of HDD must be an even ranges from 4 to 16.
Step 6 Click OK.
Step 7 Optionally, the device will automatically initialize the created array. Go to Storage > RAID Setup >
Array to view the information of the created arrray.
Figure 8-3 Array List
