B 9361 (0507)
145
2.4 Connection of the monitoring loop (for fuses and fans)
2.5 Internal fuses
2.6 Earthing
Connection Wire and connection Fusing Use
XG.26:4/5/6
GY 0.5 mm
2
,
Faston 2.8 x 0.8
max. 4 A slow
blow
Floating NO/NC
contact for sig-
naling
GY = Color code gray
Table 4: Connection of the monitoring loop (for fuses and fans)
Position Size Dimension HIMA part no.
Z 6011 4 A slow blow 5 x 20 mm 57 0174409
Z 6013 1.6 A slow blow 5 x 20 mm 57 0174169
Table 5: Internal fuses
With installation of the assembly kit a conductive connection to the
frame or a separate earth connection has to be installed according to
the EMC requirements.
Connection PE earth: Faston 6.3 x 0.8 mm.
Pay attention for the manufacturers information concerning detaching
and replugging of the Faston connectors!
