HIMA H41q User Manual

F 3349 (0641)
256
Cable plug for outputs 24 VDC
Cable plug for outputs 48 VDC
Channel Connection Color
1
2
3
4
5
6
7
8
b2
b18
b4
b20
b6
b22
b8
b24
b10
b26
b12
b28
b14
b30
b16
b32
BN
WH
YE
GN
PK
GY
RD
BU
VT
BK
WHGN
WHBN
WHGY
WHYE
WHBU
WHPK
Cable
LiYY 16 x 0.5 mm
2
L- 24 V
L+ 24 V
z2
z12
BK
RD
Flat pin plug 6.3 x 0.8 mm
Wire: q = 1 mm
2
, l = 750 mm
Lead marking of the cable plug Z 7150 / 3349 / C5 / 24P2
2-pole connection of the load
Figure 2: Lead marking of the cable plug for outputs 24 VDC
Channel Connection Color
1
2
3
4
5
6
7
8
b2
b18
b4
b20
b6
b22
b8
b24
b10
b26
b12
b28
b14
b30
b16
b32
BN
WH
YE
GN
PK
GY
RD
BU
VT
BK
WHGN
WHBN
WHGY
WHYE
WHBU
WHPK
Cable
LiYY 16 x 0.5 mm
2
-48 V
+48 V
z2
z12
BN
WH
Cable
LiYY 2 x 1 mm
2
Lead marking of the cable plug Z 7150 / 3349 / C5 / 48P2
2-pole connection of the load
Figure 3: Lead marking of the cable plug for outputs 48 VDC
