HIMA H41q User Manual

F 6214 (0606)
276
Figure 10: Active/passive transmitter 0/4 ... 20 mA
Figure 11: Voltage input 0...1 V
Figure 12: Voltage input 0...5 V
Active/passive transmitter 0/4...20 mA
Resistors for channels 1...4 (R
ab
= terminating
resistor for not used channels):
Resistor
R01, 03, 05,
07
R
ab
Value
part no.
50
Ω, 0.05%
00 0710500
3.3 kΩ, 5%
00 0471332
Voltage input 0...1 V
Resistors for channels 1...4 (R
ab
= terminating
resistor for not used channels):
Resistor
R
ab
1 R
ab
2
Value
part no.
50
Ω, 0.05%
00 0710500
3.3 kΩ, 5%
00 0471332
Voltage input 0...5 V
Resistors for channels 1...4 (R
ab
= terminating re-
sistor for not used channels):
Resi-
stor
R01, 03, 05,
07
R02, 04, 06,
08
R
ab
Value
part
no.
42.2 k
Ω,
1%
00 0751423
162 kΩ,
1%
00 0751164
1 MΩ,
5%
00 0471105
