F 6220 (0625)
298
for intrinsically safe circuits [EEx ia] IIC
1 Pt 100 resistance thermometer,
according to DIN IEC 751
input only for reference temperature
Measurand update 80 ms
Space requirement 4 SU
Operating data 5 VDC / 125 mA, 24 VDC / 300 mA
2 Useable thermocouples
Linearization in
Nominal range <
±0.1 %
Resolution 0.1 °C
Type
R
Thermocouple Pt13%Rh/Pt
Nominal range:
Input voltage -0.226 mV...21.003 mV
Temperature limits -50 °C...1760 °C
Monitored
Range of use:
Input voltage -0.226 mV...21.003 mV
Temperature limits -50 °C...1760 °C
Value in ELOP II -500...+17600 (variable type INT)
Type
S
Thermocouple Pt10%Rh/Pt
Nominal range:
Input voltage -0.236 mV...18.609 mV
Temperature limits -50 °C...1760 °C
Monitored
Range of use:
Input voltage -0.236 mV...18.609 mV
Temperature limits -50 °C...1760 °C
Value in ELOP II -500...+17600 (variable type INT)
The module must only be operated with forced ventilation (fan).
The fan (K 9203) must be installed above the subrack where the
F 6220 module is plugged in.
If the F 6220 module is operated in an H 41q, the fan (K 9212) must be
installed directly under the F 6220 module.
In order to ensure the forced ventilation, the air deflector panel M 7201
(1 HE) must to be mounted over the fan (K 9203) or over the kit H 41q.
The air deflector panel M 7201 deflects the warm air to the rear, in
order to avoid a temperature rise of the subracks and modules which
are mounted above.
