F 8627X (0650)
356
2 Functions of F 8627X
2.1 General
A H41q/H51q controller can simultaneously exchange via an F 8627X non safety-related data
with a HIMA OPC server and safety-related data via safe
ethernet. In this case, the F865x cen-
tral module ensures safety.
Beginning with operating system version 4.x, the F 8627X supports the functions "MODBUS
TCP slave" and "ELOP II TCP". The ELOP II TCP connection provides a fast data exchange
between a PADT (PC) and the F 865x central module.
2.2 Operating system versions
Overview of the operating system versions which can be loaded into the F 8627X.
The F 8627X is delivered with operating system version 4.x
Note The F 8627X has the same functions as the F 8627 and is compatible
with it. The new functions are only supported in an F 8627
X with oper-
ating system V4.x or higher.
Operating system version Properties/Mode
From OS version 2.x • HIPRO-S Mode
• A maximum of 31 HIMA PES can communicate with
each other in a safety-related manner.
• A PES can communicate with a maximum of 4 HIMA
OPC servers (see also Table 8, “Overview of the
communication with a HIMA OPC server via the
F 8627X in combination with HIPRO-S,” on page
372).
From OS version 3.x • Compatible to OS version 2.x
• HIPRO-S-DIRECT Mode
• No more than 99 safe
ethernet members can be
configured in the total network. An individual PES
can have 63 safe
ethernet communication part-
ners.
• In HIPRO-S-DIRECT mode the number of
OPC servers can be set via switch from 0 up to
14 (see also Table 8, “Overview of the communi-
cation with a HIMA OPC server via the F 8627X
in combination with HIPRO-S,” on page 372).
From OS version 4.x
(only F 8627X)
• Compatible with OS versions 2.x and 3.x
• A PES can communicate as a MODBUS TCP slave
via Port 502 and Port 8896.
• ELOP II TCP connection between a PADT (PC) and
F 8627X.
System environment required for F 8627X
• Central module F 865x, OS version (05.34) or higher
• ELOP II, version 4.1 Build (6118) or higher
Table 1: F 8627X operating system versions
