F 8627X (0650)
406
• Select Control Panel in the context menu of the new F 8627X to open the Control
Panel.
• Select
PADT->Connect in the control panel to create a connection to the F 8627X
module.
• Click the button
Stop Device in the ComEth control panel, to set the F 8627X mod-
ule into the STOP state (green RUN LED blinks).
• Select
Extra->OS Update in the ComEth control panel to open the standard dialog
for opening a file.
• Select and load the
proper operating system for the upgrade/downgrade into the
selected F 8627X module (see Chapter 8.1.1 and Chapter 8.1.2).
Note OS versions < V4.x
The PADT (PC) IP address must:
• be located in the same subnet as the F 8627 module.
• have an IP address in one of the following ranges:
• from 192.168.0.201 to 192.168.0.214 or
• from 192.168.0.243 to 192.168.0.254.
Exception: If the PADT (PC) is simultaneously used as an OPC server
and already has own one of the OPC server IP addresses, it also can
also use this IP address.
If several network cards are available on the PADT (PC), a corre-
sponding routing entry must be set for the network card which is used
for connection to the F 8627.
OS versions
≥ V4.x
Any free IP address for the PADT may be used. If the PADT IP
addresses of the PADT and the F 8627X are located in different sub-
nets, a routing entry for the subnet of the F 8627X is required on the
PADT (PC).
The next step causes a communication loss, if no redundant F 8627X
module exists or if the redundant module does not have any connec-
tion!
If the operating system download of the F 8627X was aborted, the
F 8627X must
not be removed!
Close the
ComEth control panel and reopen it. Repeat the previous
step to load the F 8627X operating system.
Note After successfully downloading the F 8627X operating system, the
F 8627X module must be rebooted
. After rebooting the new operat-
ing system is started. Until then, the F 8627X operates using with the
old operating system.
