HIMA H41q User Manual

F 8628X (0650)
412
2.3 Specifications for HIMA PROFIBUS-DP slaves
PROFIBUS is an international, open Fieldbus standard which was standardized in the
EN 50170 Fieldbus standard.
Please contact your Regional PROFIBUS Association (RPA) or refer to the Internet page
www.profibus.com for further information.
The functionality of the HIMA PROFIBUS-DP protocoll meets the requirements of EN 50 170
(DP V0).
Table 1: Specification of the HIMA PROFIBUS-DP slave
Sizes Comments
RPA ident number 0x00EA Assigned by the RPA
(PNO in germany)
GSD file HIQ200EA.GSD The GSD file for configurating a
H41q/H51q PROFIBUS-DP slave in
a PROFIBUS-DP master can be
downloaded from the internet page
www.hima.de
HIMA PROFIBUS-DP
station address
To be set via switch 1 Permissible station address
from 0 to 125
Baud rates 9.6 kBit/s
19.2 kBit/s
45.45 kBit/s
93.75 kBit/s
187.5 kBit/s
500 kBit/s
1.5 MBit/s
3 MBit/s
6 MBit/s
12 MBit/s
Baud rate that can be set via switch 2
45.45 kBit/s
(OS version 2.18 and higher).
Transmission RS 485 Most frequently used transmission
mode for PROFIBUS, often referred
to as H2
Input max. 192 Byte Inputs + outputs
maximum number 256
Output max. 240 Byte Inputs + outputs
maximum number 256
Min. slave Interval 3 ms
Accuracy of
PROFIBUS-DP
watchdog monitoring
+/- 10 ms
Modes of connecting the
HIMA PROFIBUS-DP
slave
In accordance with the
international
PROFIBUS standard
EN 50170
Cable lengths, terminating resistors
etc. have to be considered
