F 8628X (0650)
411
2.2.2 Procedure for exchanging a redundant F 8628X in a redundant
H41q/H51q controller
Make sure that you connect the Ethernet cable to the Ethernet socket
(10/100BASE-T) and the HSR cable to the HSR socket (HSR).
The respective connectors must be pressed in until they snap into their
sockets.
1. Unplug communication cable (PROFIBUS-DP).
2. Unplug communication cable (Ethernet).
3. Corresponding central module (e.g. F 8650X) with operating system
• Version below (05.34): remove the central module!
• Version beginning with (05.34): erase application program manually to deactivate
the central module (see operation system manual "Erasing the application pro-
gram")
4. Unplug HSR cable BV 7053 (if used).
5. Remove communication module F 8628X.
6. Check the new F 8628X
• Check the DIP-switch settings
(see chapter Chapter 4 and compare to the exchanged F 8628X).
• Check whether if the operating system (see sticker on the F 8628X) support the
used function (e.g. "ELOP II TCP" from OS version 4.x on)!
7. Plug the new communication module F 8628X.
8. Plug the HSR cable BV 7053 (if required).
9. Corresponding central module (e.g. F 8650X) with operating system
• Version below (05.34): plug the central module!
• Version beginning with (05.34): push the button "Ack" to activate the central
module (see operation system manual "Self-Education" )
10. Wait until the LED "RUN" on the F 8628X lights continiously.
11. Plug the communication cable (Ethernet).
12. Plug the communication cable (PROFIBUS-DP).
Note The ARP entry on the PADT (PC) must be deleted if the new F 8628X
has the
same IP address as the old F 8628X.
If the new F 8628X has the same IP address it cannot be connected to
the PADT (PC).
Example: Delete the ARP entry of an F 8628X with
IP address
192.168.0.67.
• Start the "Dos Shell" on the PADT (PC)
• Enter the command
arp -d 192.168.0.67.
