F 8628X (0650)
414
4 Functions of the switches
4.1 Functions of switch 1 (S1)
Table 4: Functions of switch 1 (S1)
S1 ON OFF Description
1 1 0 The PROFIBUS-DP Slave address
(0 to 125) for the F 8628X is set via switches
1/1-7 (See Table ).
22 0
34 0
48 0
516 0
632 0
764 0
8ID_IP
ON
ID_IP
OFF
For OS versions < 4.x no function
ID_IP ON
The bus station number (ID) which is set on
the F 865x central module via switches
(S1 1-7), is used as Res-ID, if no Res-ID could
be determined from the loaded user program.
ID_IP OFF
The bus station number (ID) which is set on
the F 865x central module via switches
(S1 1-7), is never used for the Res-ID.
