4.1.1
Switches 1/1-7
The switches 1/1-7 a
re used to set PROFIBUS
-DP Slave address (0 to 125) for th
e
F
8628X
communication module
.
T
able 5: Settings of switch 1/1-7
Switch 1
PROFIB
US-DP
address
0
1
2
3
4
5
6
7
8
""
124
125
On
Off
On
Off
Positions white
switch:
Legend
:
White switch in
position
OFF
White switch in
positio
n ON
Not used
switch
