HIMA H41q User Manual

F 8628X (0650)
416
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
4.2 Functions of switch 2 (S2)
Table 6: Functions of switch 2 (S2)
4.2.1 Switch 2/5-8
The switches 2/5-8 are used to set the F 8628X module's baud rate for communicating as a
PROFIBUS-DP slave.
Table 7: Settings of switch 2/5-8
S2 ON OFF Description
1 Ethernet
Channel1
Ethernet
Channel2
F 8628X allocation to the Ethernet channel 1 or Ethernet
channel 2.
2 - - Not used
3 - - Not used
4 - - Not used
5 ON OFF The baud rate for the F 8628X module is set via
switches 2/5-8 (See Table 6).
6ON OFF
7ON OFF
8ON OFF
Switch 2 Baud rate
9.6 kBit/s
19.2 kBit/s
93.75 kBit/s
187.5 kBit/s
500 kBit/s
1.5 MBit/s
3MBit/s
6MBit/s
12 MBit/s
45.45 kBit/s
1)
On
Off
On
Off
Positions white switch:
Legend :
White switch in
position OFF
White switch in
position ON
Not used
switch
