Note: Do not change the settings of the following items. If you change the
settings, UEFI may not start up.
•
Adapters and UEFI Drivers
• Devices and I/O Ports
• Operating Modes
• Legacy Support
• Storage
• Network
However, when 1 Gb 4-port/8-port LAN mezzanine card is installed in the
mezzanine card slot 4 of storage expansion blade, change the Devices and
I/O Ports configuration. For details, see
Storage expansion blade settings on
page 2-19.
The following table shows description of menu items appeared in the left side
of the window.
Table 2-6 System Settings menu items
Menu items Description
Adaptors and UEFI
Drivers
Displays information about adapters and UEFI drivers on the
server blade.
Processors Displays and provides option to change the processor settings.
See Processors sub menu on page 2-7.
Memory Displays and provides option to change the memory settings.
See Memory sub menu on page 2-9.
Devices and I/O Ports Displays devices and I/O port options of settings. See Device
and I/O Ports sub menu on page 2-26.
Operating Modes Selects the operating mode desired based on your preference.
Legacy Support Selects the legacy support.
System Security Selects the TPM setup options.
See System Security sub menu on page 2-10.
RAS Configuration Sets RAS configuration.
See RAS Configuration sub menu on page 2-12.
Storage Selects this option to see all the Storage Device options.
Network Selects the Network setup options
Processors sub menu
Select an item to display or set, and press Enter.
The following table shows description of menu items appeared in the left side
of the window.
Select an item to display or set, and press Enter.
UEFI setup menu
2-7
Hitachi Compute Blade 500 Series EFI User's Guide
