Honeywell 5704

1-6
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
Four Channel
Control Card
Quad Relay
Interface Card
DC Input Card
Engineering
Card
8/16-Way
AC to DC PSU
Backplane
Interface
Sensors
PC, Printer or
Engineering Key
Interface Section
Control Card Section - RFI Protected
Sub Rack
Figure 1 5704 Control System
RS232
Four Channel
Control Card
Quad Relay
Interface Card
Expansion Relay
Card
Front Panel
Blanking Panel
Sensors
Option Module
Alarm Update
MODBUS or
Printing Output
Optional Alarm
Update Panel
*
*
*
*
Interconnecting Cable for
Front Access Racks.
CHAPTER 1 - SYSTEM CONCEPT
