Honeywell 5704

1-7
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
Engineering
Card
Front Access
8 or 16-Way
4 x
Sensor
16 x Relay
Relay Interface
Assembly
OR
Figure 2 5704 Control System Over View
Rear Access
8 or 16-Way
MODBUS
Interface
Module
Master Alarm
Update Module
Event Print Module
Blank
Panels
Four
Channel
Control
Cards
Analogue
Output
Modules
4 x Relay
Quad Relay
Interface Card
4 x
Sensor
DC Input
Card
CHAPTER 1 - SYSTEM CONCEPT
