CHAPTER 6 - OPERATING INSTRUCTIONS
17/10/96 1:42
Slot : 04.3
Card Type : 5704
Sensor Type : 4 - 20mA
S/W : v01.00
Serial Number : 01234A02
Range : 0 - 100
Units : LEL
Sensor : 780
Gas : Methane
Tag : Vent 04
First Span : 10/04/96
Last Span : 16/09/96
Cal. rem. : 06 months
A1 : 0025 %fsd
A2 : 0050 %fsd
A3 : 0076.8 %fsd
Relay 01 active low
Local events assoc'd to this relay
Events : FT
Relay 02 active high
Local events assoc'd to this relay
Events : A1
Relay 03 active high
Local events assoc'd to this relay
Events : A2
Relay 04 active high
Local events assoc'd to this relay
Events : A3
Relay 12 active high
Local events assoc'd to this relay
Events : A3
Relay 13 active high
Local events assoc'd to this relay
Events : A2
Relay 14 active high
Local events assoc'd to this relay
Events : A1
Relay 15 active high
Local events assoc'd to this relay
Events : IN
Relay 16 active high
Local events assoc'd to this relay
Events : FT
Complex update activates relays:
13
Update assoc'd with the following
Events : A3 A2 A1
Note: 1. The information printed will vary slightly depending on the
type of control card tted.
2. If an RS232 device is not connected or is not able to accept
characters, the selected control card display will show
XXXX.
