CHAPTER 6 - OPERATING INSTRUCTIONS
To output a summary of the whole rack, proceed as follows:
(1) Plug an RS232 printer into the Engineering Card serial port.
(2) Push the up (
) and down ( ) buttons simultaneously without any
channel card being selected and the following data will be printed:
15/08/96 12:05
Type : Engineering Card
S/W : v00.70
Eng key override : inactive
Customer name :
DMT
Customer site :
Essen
Serial No : 01234A17
--
Slot : 01
Type : 5704
S/W : v01.00
Serial No : 01234A01
Tag : Unknown
Gas : Unknown
Range : 0 - 100
Active alarms : FT
--
Slot : 02
Type : 5704
S/W : v01.00
Serial No : 01234A02
Tag : 23C-03
Gas : Methane
Range : 0 - 100
Active alarms : A1
--
Slot : 12
Type : 5701
S/W : v00.75
Serial No : 01234A12
Tag : Unknown
Gas : Unknown
Range : 0 - 100
Active alarms : None
Note: The information printed will vary slightly depending on the type of
control card tted.
