6 Process Information Displays
6.1 Overview
This chapter provides description about the process information displays.
The process information displays contain information about the process
only, and no control of the process is possible through these displays.
The process information displays can be found in the Favorite and
Standard Categories. They include:
• Advanced Color Map
• Data Display
• High Resolution Profile
• Limit Alert
• Multiple Profile
• Production Data
• Profiles Display
• Quality Summary
• Recipe Change
• Trend and Fixed Point
• Trend and Profile
• Trend Plot
All the listed display may be or may not be in the same order on your system, since it may
be configured differently.
6.1.1 User Management
The Station consists of the following views. Depending on the user rights the displays can
be viewed in one of the following:
• Manager view
• Operator view
User access is restricted based on the type of view. For example, manager can view and
has full access to all the components and its parameters in the application, while the
operator has a restricted access and can view some or few parameters only.
