6. Once you are ready to start collecting report information about the product that you
are currently making, press the Recipe Start button. The display message changes to
Recipe Start and accumulations for this product begin.
6.10 Multi Profile Display
The Multiple Profiles display allows operators to view four profiles in a single graph. Each
profile shows the CD variations for the selected variable.
Fig. 130. Multi Profile Display
In the Multi Profiles Display, the values that are not generated at a cursor
point on a graph are displayed as blank instead of NANs under bins:
Value column.
