2 Scanner Safety and Local Controls
The Experion MX QCS may be connected to a variety of scanners. Each scanner is
equipped with a system of local control operation and safety features. In general, the items
and concepts are applicable to all scanners but the specific examples and figures that are
explained in this chapter is for the Model Q4000-80 series. Check the installation and/or
maintenance manuals for a specific scanner for more information on operation or
troubleshooting these items.
For Precision Platform 4000-01 scanner concepts and details refer to Appendix A.
Fig. 1. Experion MX O-Frame Scanner Model Q4000-80
Failure to read this chapter and any referenced manuals or sections
contained within this manual could lead to serious injury.
