Average is the average value of the data for the displayed variable, which
includes the data that is not shown when zoomed in. If the variable is
being displayed around average, a green arrow is shown to the right of
the label.
Visible column shows the visibility of the Y-axis and profile for the
selected profile. If Y-axis of the selected profile is visible then the text in
the respected column is changed to “Yes” and if Y-axis is not visible then
text in the respective column is changed to “No”.
X-Axis shows the visibility of the X-axis for the selected profile. If X-axis is
visible then text is displayed as “ON” else the column is left blank.
When you click the Frozen At column forth respective profile, the frozen
time is displayed in the column with yellow text color and the profile color
is set to yellow. When this column is clicked second time, the frozen time
disappears and column is left blank and the frozen profile disappears
from the display, and the frozen profile is saved locally. It this
measurement is viewed on a different display on the same station (if
different display is using the same measurement profile HMIWeb
component), the frozen status is still maintained. However, that frozen
profile will not be available on stations other than the one on which the
frozen request was made. It is also operator-independent, so if an
operator freezes a profile and logs out, anyone else who logs into that
station can see the frozen profile. The frozen information is not lost if the
machine is restarted.
6.10.3 Scale Information
Fig. 132. Scale Button
Scale column allows a user to scale the measurement data on the profiles. Click on the
scale column and the QcsScalingSelection popup appears.
