• Power tracks to carry the power, air, and coolant to the heads, and the sensor measurement data to the PMP
• A Precision Measurement Processor (PMP), either mounted to the scanner (4000-01 model) or set up remotely (4000-
21 model) including:
A computer that acquires, processes, and transmits data between the scanner and the Da Vinci Server
A Power Distribution Assembly that provides filtered 220 VAC to power the drive motor, and a 220/56 VAC
transformer to power the heaters which provide stable internal environments for the heads, air wipes, and sheet
guides
Power Supplies that provide 24 VDC to the sensors
A Termination PCB that provides a central termination point for the power tracks and scanner control cables, and
signal conditioning for analog and digital I/O
