SCANNER SAFETY AND LOCAL CONTROLS
6510020335
23
2.2.2.3 Electric Shock
Within the end bells, some terminations are not completely covered by access shields or
insulation. At these locations a user could come into contact with AC power at 208–240 V
AC levels.
Electrical shock warning labels (see Figure 18) have been placed in locations where bare
terminations pose electrical shock hazards (see Figure 19. In areas marked with electrical
shock warning labels, be careful with hands and fingers if power is not properly disabled.
Fig. 18. Electric Shock Warning Label
Fig. 19. Cable End Electrical Terminal Shock Warning
