Click on Current Color Code to open Simple Recipe Change Pop-up.
4. Scanner Modes:
The status of the scanners is shown in the Application Status Zone of every display. In
multiple scanner systems, scanner number 1 is the closest to the wet end. Scanner
number 2 is the second closest to the wet end, and so on.
When both the scanners are scanning, the mode indicates SCANNING 1 2 and
displays the radiation symbol to indicate that the shutter on the reel basis weight
gauge is open.
With only the breaker stack scanner, the mode indicates SCANNING 1 and does not
display the radiation symbol because the breaker stack scanner does not have a basis
weight gauge.
With both scanners stopped, the mode indicates OFFSHEET 1 2.
Click on this Scanner Modes to open Scanner Control pop-up.
Following are the scanner modes:
• OFFLINE
• SCANNING
• OFFSHEET
• STANDARDIZE
• BACKGROUND
• SINGLE POINT and MAINTENANCE
OFFLINE indicates that the scanner has been taken offsheet by the local scanner control
buttons. Scanning must be re-started with the same scan control buttons on the scanner
frame. This is a safety feature, which alerts any personnel in the vicinity of the scanner that
the heads are about to resume scanning before pressing the SCAN button at the scanner.
OFFSHEET occurs automatically on a paper break. It also occurs when you send the
sensor heads off the sheet using the operator console. STANDARDIZE and
BACKGROUND indicates that the scanner is being recalibrated. The scanner
automatically resumes scanning shortly.
SINGLE POINT indicates the scanner is reading a specific position on the sheet. This is an
operator-initiated action accessible through the scanner control display (see Figure 73).
MAINTENANCE indicates that maintenance personnel are performing maintenance tasks
on the scanner.
