128 IFP-300 Series Manual — P/N LS10145-001SK-E:C 4/6/2022
System Operation Panel Operating Modes
When looking at the LCD, the screen will display FIRE for the “Fire System”, or CO for the “CO System”. The highest priority event will
display first and include the event count.
Press the down arrow to view the location and type of alarm, supervisory, or trouble. If the panel is programmed to Auto Display Event,
information describing the highest priority active event will display on the first two lines. Auto Display Event activates after two minutes of
annunciator inactivity.
FIRE: ALARM SUPERVISORY TROUBLE
CO: ALARM SUPERVISORY
EMERGENCY: ALARM SUPERVISORY
<Press for status>
Figure 9.4 Highest Priority Event Display
FIRE ALARM: Waterflow Sw
[Site 01: Panel 01] [Z001] [M97:M031]
FIRE <ALM>
<Press for status>
site
panel number module number
Figure 9.5 Event Display after Two Minutes Sitting Idle
Operating
Mode
Occurs When System Behavior In This Mode You Can
Normal No alarm, supervisory,
or trouble condition
exists and menus are
not in use.
SYSTEM POWER LED is on.
The All Systems Normal display indicates that the
system is in normal mode. The current date and time
display on the last line of the LCD.
Enter the appropriate code, or rotate the key to activate
the Main Menu.
Alarm
A smoke detector
goes into alarm or a
pull station is
activated.
CO detector goes into
alarm.
If more than 3
categories are active
at a single time, the
screen will display as
shown.
The system will report events to the central station.
The onboard annunciator will sound loud, steady
beeps to distinguish alarm signals. For a fire alarm,
the sequence is a loud steady beep.(Any notification
devices attached to the system will also sound). For
an ECS Alarm, the sequence is four seconds on, one
second off.
The GENERAL ALARM LED will turn on.
The LCD displays a screen similar to this one.
Pressing the down arrow will display the location
macro, date/time stamp, and site/panel number if
applicable.
Pressing the down arrow key to view the type and
location of alarm. (Message will alternate with the
date/time display.)
Press the down arrow to view the alarm. A screen similar
to this one displays.
Press SILENCE and enter an Access Code (or activate
the key) to silence the annunciator (and any notification
devices attached to the system).
When the alarm condition clears, press RESET and
enter a code (or activate the key) to restore the panel to
normal.
Table 9.4 Panel Operating Modes
Site 1
FIRE: ALARM
EMERGENCY: ALARM
<Press for status>
Site 1
CO: ALARM
<Press for status>
FIRE: ALARM SUPERVISORY TROUBLE
CO: ALARM
EMERGENCY: ALARM SUPERVISORY
SYSTEM: TROUBLE
Site 1 Panel 1
FIRE ALARM: Waterflow Sw
SBUS 97 MODULE 3
08/03/21 01:45:52PM
