Panel Operating Modes System Operation
Supervisory
The system detects a
supervisory condition.
A Supervisory with a
CO detector.
The system will report events to the central station.
The onboard annunciator sounds a loud, pulsing beep
to distinguish supervisory signals. For fire supervisory
signals, the sequence is two seconds on, two seconds
off. For ECS supervisory signals, the sequence is two
seconds on, three seconds off.
The SUPERVISORY LED will turn on.
The LCD displays a screen similar to this one.
Pressing the down arrow to display the location
macro, date/time stamp, and site/panel, if applicable.
Press the down arrow to view the type and location of
the Supervisory event. The message will alternate
with the time/date display.
Press the down arrow to view the fire supervisory
condition. A screen similar to this one displays.
Press SILENCE and enter an Access Code (or activate
the key) to silence the annunciator.
Once the supervisory condition has been corrected, the
system will restore automatically.
Trouble
A system trouble
condition occurs.
A trouble condition
with a CO detector
The system will report events to the central station.
The onboard annunciator sounds a loud, pulsing beep
in the sequence 0.75 second on, eight seconds off.
The SYSTEM TROUBLE LED will turn on.
The LCD displays a screen similar to this one.
Press the down arrow to display the location macro,
date/time stamp, and site/panel, if applicable.
Press the down arrow to view the type and location of
the Trouble event. The message will alternate with the
time/date display.
Press down arrow to view the fire trouble. A screen
similar to this one displays.
Press SILENCE to silence the annunciator.
Once the trouble condition has been fixed, the system
will restore itself automatically.
Pre-alarm A single detector trips
in a 2-Count zone.
(2-Count means two
detectors must trip
before an alarm is
reported.)
The touchpad piezo beeps.
The LCD displays a screen similar to this one.
Press the down arrow to display the location macro,
date/time stamp, and site/panel, if applicable.
Press down arrow to view the Prealarm. A screen similar
to this one displays.
All system operations are available in this mode.
Reset The RESET button is
pressed followed by a
valid code, if
necessary.
All LEDs are on briefly then the LCD displays “RESET
IN PROGRESS”. If the reset process completes
normally, the date and time normal mode screen
displays.
Menus are not available during the reset process.
Operating
Mode
Occurs When System Behavior In This Mode You Can
Table 9.4 Panel Operating Modes (Continued)
Site 1
FIRE: SUPERVISORY
<Press for status>
Site 1
CO: SUPERVISORY
<Press for status>
Site 1 Panel 1
FIRE SUPERVISORY: Supervisory Sw
SBUS 97 MODULE 3
08/03/21 01:45:52PM
Site 1
FIRE: TROUBLE
<Press for status>
Site 1
CO: TROUBLE
<Press for status>
Site 1 Panel 1
FIRE TROUBLE: Supervisory Sw
SBUS 97 MODULE 32
08/03/21 01:45:52PM
Site 1
FIRE: PREALARM
<Press for status>
Site 1 Panel 2
FIRE PREALARM: Det-Photo
SBUS 97 MODULE 33
08/03/21 01:45:52PM 1 of 1
