20 IFP-300 Series Manual — P/N LS10145-001SK-E:C 4/6/2022
Prerequisites for Installation Calculating Current Draw and Standby Battery
IDP-CONTROL-6 SLC Standby 2.65 mA mA
Alarm: 35 mA mA
Aux Pwr Standby 8 mA mA
Alarm: 20 mA mA
IDP-RELAY Standby/Alarm: 0.255 mA mA mA
IDP-RELAY-6 Standby: 1.9 mA mA
Alarm: 32 mA mA
IDP-RELAYMON-2 Standby: 1.3 mA mA
Alarm: 24 mA mA
IDP-ZONE Aux Pwr Standby 12 mA mA
Alarm: 90 mA mA
SLC Standby: 0.27 mA mA
Alarm: 5.1 mA
IDP-ZONE-6 Aux Pwr Standby 50 mA mA
Alarm: 70 mA mA
SLC Standby 2.3 mA mA
Alarm: 40 mA mA
SLC Accessories
B200SR/-W/-IV Sounder Base Aux Pwr Standby: 0.5 mA mA
Alarm: 35 mA mA
SLC Standby 0.3 mA mA
B200S/-W/-IV Intelligent Sounder
Base
Aux Pwr Standby: 0.5 mA mA
Alarm: (high vol) 35 mA mA
SLC Standby 0.3 mA mA
B200SR-LF/-W/-IV Low Frequency
Sounder Base
Aux Pwr Standby: 1 mA mA
Alarm: 125 mA mA
B200S-LF/-W/-IV Intelligent Low
Frequency Sounder Base
Aux Pwr Standby 0.55 mA mA
Alarm (high vol) 140 mA mA
SLC Standby 0.30 mA mA
B224RB/-W/-IV Relay Base Standby/Alarm: 0.17 mA mA mA
RTS151 Alarm: 10 mA
mA
RTS151KEY Alarm: 12 mA
mA
RA100Z Alarm: 10 mA
mA
SLC Isolator Devices
IDP-ISO (Isolator Module) Standby: 0.45 mA mA mA
Isolation: 17 mA
ISO-6 (6 Fault Isolator Module) Standby: (per circuit) 0.45 mA mA
Isolation: (per circuit) 17 mA mA
B224BI/-W/-IV Isolator Base Standby: 0.45 mA mA
Isolation: 15 mA mA
Accessories Modules
5
6815 SLC Loop Expander Standby: 78 mA mA
Alarm: 78 mA mA
RA-2000 Remote LCD Annunciator Standby: 27 mA mA
Alarm: 53 mA mA
RA-1000 Remote LCD Annunciator Standby: 58 mA mA
Alarm: 68 mA mA
RA-100 Remote LCD Annunciator Standby: 59 mA mA
Alarm: 92 mA mA
Device # of Devices Current per Device
Standby
Current
Alarm Current
Table 3.2 Current Draw Worksheet for IDP SLC Devices (Continued)
