Calculating Current Draw and Standby Battery Prerequisites for Installation
5824 Serial/Parallel Module Standby/Alarm: 45 mA mA mA
5496 NAC Expander Standby/Alarm (SBUS): 10 mA mA mA
RPS-1000 Power Supply Standby/Alarm (SBUS): 10 mA mA mA
5865-4 LED Annunciator
(with reset and silence switches)
Standby: 35 mA mA
Alarm: 145 mA mA
5865-3 LED Annunciator Module Standby: 35 mA mA
Alarm: 145 mA mA
5880 LED I/O Module Standby: 35 mA mA
Alarm: 200 mA mA
5883 Relay Interface Standby: 0 mA mA
Alarm: (22 mA/relay) 220 mA mA
ECS-50W Voice Amplifier
with/without ECS-CE4
Standby/Alarm (SBUS): 10 mA mA mA
ECS-125W Voice Amplifier
with/without ECS-CE4
Standby/Alarm (SBUS): 10 mA mA mA
ECS-INT50W Internal Amplifier Standby: 52 mA mA
Alarm @ 25V: 275 mA mA
Alarm @ 70V: 310 mA
mA
ECS-DUAL50W Dual Voice Amp Standby/Alarm (SBUS): 10 mA mA mA
ECS-50WBU Back-Up Amplifier Standby/Alarm: 10 mA mA mA
ECS-VCM Voice Control Module Standby: 70 mA mA
Alarm: 100 mA mA
ECS-NVCM Voice Control Module Standby/Alarm: 59 mA mA mA
ECS-RVM Remote Voice Module Standby: 60 mA
Alarm: 80 mA
ECS-SW24 Switch Expander Standby: 10 mA mA
Alarm: 25 mA mA
ECS-RPU Remote Paging Unit Standby: 70 mA mA
Alarm: 100 mA mA
ECS-LOC Local Operating Console Standby: 87 mA mA
Alarm: 133 mA mA
ECS-LOC Local Operating Console
with one ECS-SW24
Standby: 97 mA mA
Alarm: 158 mA mA
ECS-LOC2100 Local Operating
Console
Standby: 87 mA mA
Alarm: 133 mA mA
ECS-LOC2100 Local Operating
Console with one ECS-SW24
Expander
Standby: 97 mA mA
Alarm: 158 mA mA
ECS-LOC2100 Local Operating
Console with two ECS-SW24
Expanders
Standby: 107 mA mA
Alarm: 183 mA mA
Network Cards
SK-NIC Network Interface Card Standby/Alarm: 21 mA mA mA
SK-FML Fiber Optic Multi Mode Standby/Alarm: 53 mA mA mA
SK-FSL Fiber Optic Single Mode Standby/Alarm: 79 mA mA mA
Wireless Modules
WIDP-WGI Wireless Gateway Max current using ext supply 40 mA mA mA
Max current SLC Power 24 mA mA mA
A Total System Current
Auxiliary Devices Refer to devices manual for current rating
Device # of Devices Current per Device
Standby
Current
Alarm Current
Table 3.2 Current Draw Worksheet for IDP SLC Devices (Continued)
