Honeywell Farenhyt Series - Section 8: Programming Overview; 8.1 JumpStart AutoProgramming; 8.1.1 Input Points; 8.1.2 Output Points

IFP-300 Series Manual — P/N LS10145-001SK-E:C 4/6/2022 87
Programming Menu Quick Reference Programming Overview
Point
(cont.)
SD, IDP, and SK
Devices on
Internal SLC,
External 6815, and
External 5815XL
Enter Pt Select
Sensor
RELAY
2,3,4,5,6,7
OUTPUT PT Select
Group
Section 8.5
AUX RESET
AUX DOOR
SLC LED
4,7
LED Number 1-80
LED Function Notif. Output
Unused
DETECTOR
2,3,5,6
2-WIRE SMOKE Select Zone
W. Gateway
2,3,5,6
W SWITCH
2,3,5,6,8
Same as SWITCH
W-RELAY
2,3,5,6,8
Same as Relay
UNUSED
DETECTOR
2,3,4,5,6,7
PHOTO No Base
SDR BAS Single station or
Multi station
Silence or Non-
Silence
RLY BAS
I-SdrBa
(Intelligent
Sounder
Base)
2,3,5,6
Latch or non-latch,
Single station or
Multi station,
Silence or Non-
Silence, volume
high (default) or
low
ION No Base
SDR BAS Single station or
Multi station
Silence or Non-
Silence
RLY BAS
I-SdrBa
(Intelligent
Sounder
Base)
2,3,5,6
Latch or non-latch,
Single station or
Multi station,
Silence or Non-
Silence, volume
high (default) or
low
Menu Options/Defaults Comments
Table 7.4 Programming Menus Quick Reference List (Continued)
