Point
(cont.)
SD, IDP, and SK
Devices on
Internal SLC,
External 6815, and
External 5815XL
Enter Pt Select
Sensor
DETECTOR
2,3,4,5,6,7
HEAT
2,3,4,5,6,7
No Base Section 8.5
SDR BAS Single station or
Multi station
Silence or Non-
Silence
RLY BAS
I-SdrBa
(Intelligent
Sounder
Base)
2,3,5,6
Latch or non-latch,
Single station or
Multi station,
Silence or Non-
Silence, volume
high (default) or
low
DUCT
2,3,4,5,6,7
No Base
DCT RLY
ION DUCT
4,7
No Base
DCT RLY
2-WIRE SMOKE
4,7
ACCLIMATE
2,3,5,6
No Base
SDR BAS Single station or
Multi station
Silence or Non-
Silence
RLY BAS
I-SdrBa
(Intelligent
Sounder
Base)
Latch or non-latch,
Single station or
Multi station,
Silence or Non-
Silence, volume
high (default) or
low
HEAT-HT
2,3,5,6
No Accessory base
SDR base Single station or
Multi station
Silence or Non-
Silence
RLY base
I-SdrBa
(Intelligent
Sounder
Base)
Latch or non-latch,
Single station or
Multi station,
Silence or Non-
Silence, volume
high (default) or
low
PHOTO-
HEAT
2,3,5,6
No Accessory base
SDR BAS Single station or
Multi station
Silence or Non-
Silence
RLY BAS
I-SdrBa
(Intelligent
Sounder
Base)
Latch or non-latch,
Single station or
Multi station,
Silence or Non-
Silence, volume
high (default) or
low
BEAM
2,3,5,6
SUP DET
2,3,4,5,6,7
Same function
as DETECTOR
LATCH
NON-LATCH
Menu Options/Defaults Comments
Table 7.4 Programming Menus Quick Reference List (Continued)
