Chapter 6 – Maintenance
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
242
looseness; some play is normal. Adjust the
spring(s) on the battery contact PCB assembly,
or replace the battery end plate.
Replace or recharge the batteries.
Terminals in battery
end plate PCB
corroded and/or dirty
If the terminals on the battery end plate PCB
are discolored or corroded, clean them with a
pencil eraser.
Internal short circuit,
battery wire pinched
Remove the connector end plate and carefully
inspect the internal wires for damage (see
Section 6.3.7.2 “Disassembly”).
Internal power
connectors offset or
damaged
Check internal connectors for position,
looseness, and/or damage.
Spring loose and
only making
intermittent contact
Springs in the battery contact PCB assembly
must be clean and not excessively loose. If
there is a problem with looseness, the eyelet
that holds the spring must be re-pressed or the
assembly replaced.
Conductive debris
loose in unit
Internally inspect the unit for loose debris, for
example, a screw.
Problem: Unit Turning Off/Resetting While Collecting Data
Short circuit on
photocell/magnetic
pickup cable
Inspect the cable. Replace it if it is damaged.
Internal connections
loose or damaged
Remove the connector end plate (see
Section 6.3.7.2 “Disassembly”). Inspect the
unit for loose connectors, pinched and/or
broken wires.
Photocell probe
failed and is causing
Inspect the photocell. Replace it if necessary.
